Product Specifications
# of Lines 16 Laser Wavelength 905nm
Laser Safety Class 1 eye safe Blind Spot ≤0.4m
Range 150m(80m@10% NIST)  Range Accuracy(Typical) Up to ±2cm
Horizontal FoV 360° Vertical FoV 30°
Horizontal  Resolution 0.1°/0.2°/0.4° Vertical Resolution 2.0°
Frame Rate 5Hz/10Hz/20 Hz Rotation Speed 300/600/1200rpm (5/10/20Hz)
Points Per Second ~300,000pts/s(Single Return)   ~600,000pts/s(Dual Return) UDP Packet include Spatial Coordinates, Intensity, Timestamp, etc.
Ethernet Connection 100 Mbps Output UDP packets over Ethernet
Operating Voltage 9V - 32V Operating Temperature -30°C ~ +60°C
Power Consumption 12W Storage Temperature -40°C~ +85°C
Ingress Protection IP67 Time Synonization $GPRMC with 1PPS,
Dimension φ109mm *  H80.7 mm Weight (without cabling) ~0.87 kg
